LG RT-44A85 Series User Manual

- 49 -
EXPLODED VIEW PARTS LIST
105 3680V00048A LENS,SEKINOS SSM-100(60) LENS ASSEMBLY .
107 4810V00780C BRACKET, PRT ASSY RN-44NZ35,60H, 49NZ25H MP03AA NON SSM-100 B CLENS+COUPLER+CPT
108 4810V00780B BRACKET, PRT ASSY RP-45NZ60P MP03AA NON SSM-100 G CLENS+COUPLER+CPT
109 4810V00780A BRACKET, PRT ASSY RN-44NZ35,60H, 49NZ25H MP03AA NON SSM-100 R CLENS+COUPLER+CPT
120 6400VA0015A SPEAKER,GENERAL C151PX-373K14 LG C&D 8 OHM 15W/25W 86DB 154X104MM
121 120-237C SPEAKER,FULLRANGE C060T01K145A ESTEC 8 15/20 88 . 60X60 FULLRANGE
153 6150Z-1100E DY(DEFLECTION YOKE), 2.5H 38KHZ L 400MM 07 LGPLD RN-39NZ33H 6150Z-1100B
174 174-322G POWER CORD, KUK JE VDE 2400MM HOUSING BLACK .
300 3091V00A35D CABINET ASSEMBLY, RE-56NZ21RB - MP015D UPPER
301 3091V00603D CABINET ASSEMBLY, RT-56NZ23RB STEREO MP03AB (VE WOOD C/A ASSY)
302 3211V00086N FRAME ASSEMBLY, FRONT LOWER RT-56NZ23RB .
303 4778V00012D LEG, ROLLER CASTER RN-56NZ10H POLYURETHAN 65.4MM
304 3350V00042A SCREEN, DNP NON R2 56(W) - SS ENG (17B)
305 3790V00298R FILTER(MECH), X2-56W NON NON
307 3091V00A36A CABINET ASSEMBLY, RN-56NZ10H NON NON XCANVAS
310 5020V00665B BUTTON, CONTROL RN-49NZ20H ABS, HF-380 - 3KEY
311 3550V00213A COVER, DECO RN-49NZ10HA ABS, HF-380 INDEX
312 4810V00670G BRACKET, CONTROL RN-49NZ20H SP02PB HIPS 40AF .
315 5020V00665A BUTTON, CONTROL RT-49NZ20H ABS, HF-380 4KEY NON
320 320-062J SPRING, KNOB
330 5020V00393H BUTTON, RN-49NZ10H , SET
340 6871VSMV16A PWB(PCB) ASSEMBLY,SUB PSW MP03AA M/I PWR-SW RN-44NZ73H
350 6871VSMY17A PWB(PCB) ASSEMBLY,SUB CONT MP03AB M/I LED-CONTROL RE-49NZ23RB/RT-56NZ23RB
360 6871VSMW91A PWB(PCB) ASSEMBLY,SUB CONT MP03AA M/I SUB-KEY RN-49NZ25H
410 3809V00A22B BACK COVER ASSEMBLY RE-56NZ21RB - UPPER
420 3809V00A23H BACK COVER ASSEMBLY RT-56NZ23RB NON UPPER
430 5018V00029B MIRROR, PROJECTION AHSUNG MIRROR R2 56(WIDE) FILM MIRROR
501 4810V00752C BRACKET, MAIN RU-40NZ60 MP03AA HIPS 407AF .
503 4810V00874B BRACKET, REAR AV RE-39NZ60RB MP03AB HIPS 60HR .
510 6871VSMV08B PWB(PCB) ASSEMBLY,SUB CPT MP03AB M/I EXPORT NO HIGH VOLTAGE LABEL
520 6871VMN669S PWB(PCB) ASSEMBLY,MAIN MP03AB M/I PAL-EU (POLAND) RE-56NZ23RB.AUMLKP
530 6871VDM904A PWB(PCB) ASSEMBLY,DEFLECTION MAIN2 MP03AB M/I 16:9, NARROW, 100MM EUROPE
540 6871VSMC16A PWB(PCB) ASSEMBLY,SUB CVG MP03AB CONV-OUT M/I (PAL 2MODE)
550 6871VSMV80A PWB(PCB) ASSEMBLY,SUB DIGITAL MP03AB M/I PAL (W/O PC, W/ 1080I-ADJ) RE-44NA14T
570 6871VSMY12S PWB(PCB) ASSEMBLY,SUB MP03AB M/I MICOM(PAL) W/ TXT A/C POLAND RE-56NZ23RB.AUMLKP
590 6871VSMC17A PWB(PCB) ASSEMBLY,SUB CVG MP03AB D-CON M/I
600 6871VPMA27A PWB(PCB) ASSEMBLY,POWER SUB MP-03AB AC-INPUT M/I EUROPE
610 6871VSMV11P PWB(PCB) ASSEMBLY,SUB S/IN MP03AB SIDE-AV EU+ASIA 1000MM (WHITE+BEIGE) RE-49NZ23RB
620 6871VSMX19A PWB(PCB) ASSEMBLY,SUB P/AMP MP03AB M/I PRE-AMP (PAL) 1400MM (W/O HOLDER)
630 6871VSMC13A PWB(PCB) ASSEMBLY,SUB INTER MP03AA CVG-INTERFACE M/I
650 6871VSMB45B PWB(PCB) ASSEMBLY,SUB CVG SP-02PB 56 AUTO C/G RIGHT SENSOR
660 6871VSMB45A PWB(PCB) ASSEMBLY,SUB CVG SP-02PB 56 AUTO C/G LEFT SENSOR
670 6871VSMB45C PWB(PCB) ASSEMBLY,SUB CVG SP-02PB 56 AUTO C/G TOP SENSOR
680 6871VSMB45D PWB(PCB) ASSEMBLY,SUB CVG SP-02PB 56 AUTO C/G BOTTOM SENSOR
690 6871VSMV58B PWB(PCB) ASSEMBLY,SUB VM MP03AB EU,PAL
800 4410Z-A001L FBT (FLY BACK TRANSFORMER), 4410Z-A001K 44 JW VE TYPE
810 180-836K FOCUS PACK, W18-601-02 YINYANG 180-836H
No. Part No. Description
