REPLACEMENT PARTS LIST
LOCA. NO PART NO DESCRIPTION
IC409
IC410
IC500
IC501
IC502
IC503
IC504
IC505
IC600
IC601
IC602
IC700
IC801
IC802
IC831
IC832
IC833
IC851
IC881
IC891
IC901
IC901B
IC901G
IC901R
IC902
ICT01
ICT02
ICX601
SD01
SD02
SD03
SD04
SD05
SD06
SD07
SD08
SD09
SD10
SD11
SD12
SD13
SD14
SD15
SD16
IC11
IC12
IC13
IC14
IC15
IC16
IC17
0ISS790500C
0IKE780500Q
0ISH122100B
0IMCRSO013B
0IKE780500Q
0ISS393000G
0IKE780900M
0IKE780500P
0IMCRMN001C
0IKE780800J
0ISS455880A
0ISO206900A
0ISK665813A
0IPMGSK003A
0ILI817000G
0ILI817000G
0ILI817000G
0IMO257633A
0IKE782400C
0ISK105000A
0IZZVF0018C
0IPH611190A
0IPH611190A
0IPH611190A
0IKE781200P
0IMCRMI002A
0IMCRMI002A
0IMCRNS006A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0IPRPTD001A
0TR830009BA
0TR830009BA
0TR830009BA
0TR830009BA
0TR830009BA
0TR830009BA
0TR830009BA
IC, KA7905 POWER INTEGRATION TO220 BK REGULATOR
IC, KIA7805API 3P TO-220 ST REGULATOR 5V(=KIA7805PI)
IC, PQ12RD21 4SIP ST REGULATOR -
IC, CXA2180Q SONY 64P QFP TRAY BACK-END IC
IC, KIA7805API 3P TO-220 ST REGULATOR 5V(=KIA7805PI)
IC, KA393 COMPARATOR 8DIP BK OP AMP
IC, KIA7809API TO220 ST 3P 9V REGULATOR
IC, KIA78L05BP(AT) 3P 5V,150MA
IC, MSP3411G QA B8 V3 MICRONAS 80P QFP
IC, KIA7808API 3 ST REGULATOR .
IC, KA4558D 8SOP OP AMP
IC, CXA2069Q QFP64 BK I2C BUS AV S/W
IC, STR-F6658B(LF1352) 5PIN SIP BK STR PN-43A3Y
IC, STR-A6351 SANKEN 8 DIP ST SMPS 1 CHIP
IC, LTV817M-VB 4P,DIP BK PHOTO COUPLER
IC, LTV817M-VB 4P,DIP BK PHOTO COUPLER
IC, LTV817M-VB 4P,DIP BK PHOTO COUPLER
IC, LM2576TV-3.3 5PIN ST REGULATOR HN-61A40R
IC, KIA7824API 3 ST REGULATOR .
IC, SE105N 105V ERROR AMP(NO.12)
IC, 11P ST SCAN VELOCITY MODU. HDTV (BW 10M)
IC, TDA6111Q 9SIP RGB AMP
IC, TDA6111Q 9SIP RGB AMP
IC, TDA6111Q 9SIP RGB AMP
IC, KIA7812API TO220 ST 3P 12V REGULATOR
IC, M62320P MITSUBISHI 16DIP ST I/O EXPANDER
IC, M62320P MITSUBISHI 16DIP ST I/O EXPANDER
IC, 15P TO220 ST AUDIO POWER AMP 30W
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
IC, BCS5030G1 TDK 2P SMD R/TP SENSOR
TR, BSS83 TP PHILIPS NON N-CHANNEL S/W TR
TR, BSS83 TP PHILIPS NON N-CHANNEL S/W TR
TR, BSS83 TP PHILIPS NON N-CHANNEL S/W TR
TR, BSS83 TP PHILIPS NON N-CHANNEL S/W TR
TR, BSS83 TP PHILIPS NON N-CHANNEL S/W TR
TR, BSS83 TP PHILIPS NON N-CHANNEL S/W TR
TR, BSS83 TP PHILIPS NON N-CHANNEL S/W TR
LOCA. NO PART NO DESCRIPTION
D861
IC01
IC02
IC03
IC04
IC05
IC06
IC07
IC08
IC101
IC102
IC103
IC103
IC104
IC105
IC106
IC107
IC2000
IC2003
IC2004
IC2005
IC2006
IC2007
IC2020
IC2021
IC2022
IC2023
IC2025
IC2025
IC2026
IC2027
IC2050
IC2051
IC2052
IC2053
IC2060
IC260
IC261
IC262
IC263
IC264
IC265
IC266
IC2701
IC2702
IC401
IC402
IC403
IC404
IC405
IC408
0ISK100300A
0ISM555000A
0IAL241610B
0ISS610082A
0IMCRAL003B
0IPMGSG017A
0ISG111733A
0ISG272012A
0IFA752700A
0IKE780500Q
0IFA754207A
0IKE780500Q
0IKE780500Q
0IKE780900M
0ISH052100C
0ISH323422A
0ISG111725B
0ICTMSG001A
0ITI347000A
0ITI347000A
0IAL241610B
0IMCRAL003B
0ISG111733B
0IMCRAL003B
0IPRPTO002A
0IPRPTO003A
0IPRPTO004A
0IMCRAL003C
0IPRPTO002A
0IMCRAL003C
0IMCRAL003C
0IMCRNS003A
0IMCRNS003A
0ISS290300A
0ISS290300A
0IFA752700A
0IPMGSG016A
0IPMGSG016A
0IMCRMN016B
0ISA721700C
0IMCRFA012A
0ICTMLG010A
0IMCRSO008A
0ISA392120A
0ISA392120A
0IKE358000A
0ISS393000G
0IKE781200P
0ISA784600A
0IFA754207A
0IKE358000A
IC, DIODE MODULE(RU4AM+FMLG12S) LF816
IC, SDA5550 MQFP100 BK MICOM TXT MC006A
IC, AT24C16A-10PI-2.7 8PIN DIP ST EEPROM NON
IC, 32-TSOP R/TP 1M(8BIT-128K)-SRAM(3.3V),70NS
IC, AT24C164-10PI-2.7 ATMEL 8P PDIP ST EEPROM 164K
IC, 3P DPAK R/TP REGULATOR 2.5V 0.8A
IC, TP ROW DROP REGULATOR IC 3.3V,2.5K/REEL
IC, M27W201(2M BIT 3.3V) 32PLCC TP OTP EPROM MC006A
IC, KA75270Z 3 TP RE-SET IC MC-007
IC, KIA7805API 3P TO-220 ST REGULATOR 5V(=KIA7805PI)
IC, KA75420ZTA(KA7542ZTA) 3P,TO-92 TP 4.2V RESET IC
IC, KIA7805API 3P TO-220 ST REGULATOR 5V(=KIA7805PI)
IC, KIA7805API 3P TO-220 ST REGULATOR 5V(=KIA7805PI)
IC, KIA7809API TO220 ST 3P 9V REGULATOR
IC, PQ05RD21 4SIP ST REGULATOR -
IC, PQ3RF23 4P(TO-220) 3.3V REGUL
IC, LD1117V25 3 SIP ST REGULATOR MC006A
IC, STV2050A SGS-THOMSON 80PIN TQFP
IC, LF347D 14P,SOP TP QUAD OPERATIONAL AMP
IC, LF347D 14P,SOP TP QUAD OPERATIONAL AMP
IC, AT24C16A-10PI-2.7 8PIN DIP ST EEPROM NON
IC, AT24C164-10PI-2.7 ATMEL 8P PDIP ST EEPROM 164K
IC, LD1117V33C 3SIP ST REGULATOR -
IC, AT24C164-10PI-2.7 ATMEL 8P PDIP ST EEPROM 164K
IC, 5P SOP TP SCHMITT INVERTER
IC, TC7SZ08F TOSHIBA 5P SOP TP AND GATE
IC, TC7W74F TOSHIBA 8P SOP TP D TYPE FLIP FLOP
IC, AT24C164-10SI-2.7 ATMEL 8P SOIC R/TP EEPROM
IC, 5P SOP TP SCHMITT INVERTER
IC, AT24C164-10SI-2.7 ATMEL 8P SOIC R/TP EEPROM
IC, AT24C164-10SI-2.7 ATMEL 8P SOIC R/TP EEPROM
IC, 8P DIP BK I/V CONVERTER
IC, 8P DIP BK I/V CONVERTER
IC, KA2903 8P,DIP BK DUAL COMPARATOR
IC, KA2903 8P,DIP BK DUAL COMPARATOR
IC, KA75270Z 3 TP RE-SET IC MC-007
IC, 3P D2PAK R/TP REGULATOR 1.8V 1.5A
IC, D2PAK R/TP REGULATOR 1.8V 1.5A
IC, VSP9427B-XZ-C3 MICRONAS 144P QFP
IC, LA7217M MFP14 TP SYNC SEPARATOR ML-00BA
IC, 16P SOIC R/TP 2LINE TO 1LINE DATA SELECTORS
IC, LGDT1000B LG IC QFP 128P TRAY DRP2
IC, CXA2151Q SONY 48P QFP TRAY 60LCD
IC, STK392-120 18P,SIP BK
IC, STK392-120 18P,SIP BK
IC, KIA358P DIP8 DUAL OP-AMP BK
IC, KA393 COMPARATOR 8DIP BK OP AMP
IC, KIA7812API TO220 ST 3P 12V REGULATOR
IC, 7846 SIP,10P BK V-OUT IC
IC, KA75420ZTA(KA7542ZTA) 3P,TO-92 TP 4.2V RESET IC
IC, KIA358P DIP8 DUAL OP-AMP BK
IC
TRANSISTOR
