1. Incomplete segments.
• Segment missing.
• Partial segment missing.
• Digit flickering (NOTE: Slight flickering is normal.)
2. Colon does not turn on or blink.
3. A distinct change in the brightness of one or more numbers in display.
4. One or more digits in the display are not lighting.
5. Display does not count down with time blinking or up with clock operation.
6. Display obviously jumps in time while counting down.
7. Display counts down too fast while cooking.
8. Each indicator light does not turn on after setting cooking cycle.
9. Display time of day does not reappear when cooking is finished.
10. Beep sound is not heard when correct key is touched.
5-15
(TROUBLE 1)
The following visual conditions indicate a probable defective control circuit.
CONDITION CHECK RESULT CAUSE REMEDY
1. No input can be
programmed.
Continuity.
No continuity.
Defective PCB
assembly.
Loose
connection.
Replace PCB
assembly.
Connect them
tightly.
Check the conn-
ection between
key assembly
and PCB
assembly.
2. Some inputs
cannot be
programmed.
3. Display shows a
number or figure
different from one
touched.
4. Random
programming
when touching
other pads.
5. Display is fixed
at some figure
and can not
accept any
input.
Everything works
as specified.
Still have trouble.
Defective key
assembly.
Defective PCB
assembly.
Replace key
assembly.
Replace PCB
assembly.
Replace key
assembly and
check operation.
