A16
Specifications
Picture tube
15 inch (13.8 inches viewable) FST, Non-glare, 90 degree deflection,
Darkface, 0.28 mm dot pitch
Sync Input
Horizontal Freq. : 30kHz - 54kHz (Automatic)
Vertical Freq. : 50Hz - 90Hz (Automatic)
Input Form : Separate, TTL, positive/negative
Signal input : 15 pin D-connector
Video and Audio Input
Input Form : Separate, RGB Analog, 0.7 Vp-p/75 ohm, positive
Resolution : 1024 x 768, 60Hz
RMS Audio Output : 2 W (R+L)
Speaker Impedance : 8 Ω
Power Consumption:
Power input
100-240VAC 50/60Hz 1.5A
Dimensions ( W x H x D )
16.4 x 15.0 x 15.4 inches/417 x 380 x 391 mm(with tilt/swivel stand)
Weight ( net )
31.3 lbs (14.2 kg)
Information in this document is subject to change without notice and does
not represent a commitment on the part of LG Electronics Inc.
90 Watts max
15 Watts suspend mode, stand-by mode
8 Watts DPMS-Off mode
