ASSEMBLING AND PREPARING
Preparing Built-in Camera
(This feature is not available for all models.)
1 Pull up the slide at the back of the TV.
Slide
Angle Adjustment Lever
y
Remove the protective film before using the built-
in camera.
NOTE
2 You can adjust the angle of the camera with the
angle adjustment lever on the back of the built-in
camera.
<Side View>
3 Push down the built-in camera when you are not
using it.
Name of Parts of Built-in Camera
Camera Lens
Microphone
Microphone
Protective Film
Checking the Camera’s Shooting Range
1 Press the (Home) button to access the Home
menu.
2 Select
Camera and then press the Wheel(OK)
button.
y
The optimal distance from the camera to use the
motion recognition function is between 1.5 m and
4.5 m.
NOTE
7°
5°
7°
5°
3°
5°
3°
5°
Lever Lens
Lever Lens
(Only 65/79/84UB98**)
(Only 98UB98**, UC9*)
