LG UP7500 - Wall Mounting Bracket

9
Wall Mounting Bracket
(Depending on model)
Make sure to use screws and wall mount bracket that meet the VESA standard. Standard dimensions for the wall mount kits are described in the
following table.
A
Model
43/50UP767*
43/50UP77*
43/50UP78*
43/50UP80*
43/50UP81*
55/65UP767*
55/60/65UP77*
55/65UP78*
55/60/65UP80*
55/65UP81*
Screws distance (A) (mm) 200 300
Standard screw M6 M6
Number of screws 2 2
Wall mount bracket WB21LMB WB21LMB
