15
INSTALLATION
ENGLISH
• Remove the lower screw first. The door
may fall on to the floor due to its
weight and the door can be damaged.
2
Remove 8 screws on the hinge
assembly
c
from the door.
• There are 6 screws on the front and
2 screws on the side.
3
Remove the 3 screws from the door
latch assembly
d
which is fixed
between the door and the hinge
assembly, and then remove the screw
which is fixed on the door hook.
4
Swap the position of the hinge
assembly
c
and the door latch
assembly
d
and then tighten the
screws in reverse order.
• Tighten the screw in their proper
position referring from steps 2 to 4.
5
Remove the door catch
e
from the
appliance frame by removing 2
screws and then assemble them on
the opposite side.
6
Remove the 2 decorative screws from
the appliance frame and then
assemble them on opposite side.
To Next Page
