dentification of Parts
I
WATER SUPPLY
HOSE
BLEACH
DISPENSER
FUNCTION
SELECTOR
TUB
BASE
ADJUSTABLE LEGS
DRAIN HOSE
POWER PLUG
START/PAUSE
BUTTON
Use to start or
stop the washing
machine
temporarily.
Make sure the
water does not
leak.
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its
service agents or
similarly qualified
person in order to
avoid a hazard.
Keep the drain hose
flipped down while
washing is in progress.
Use to level the washing
machine for correct
balance & spin
operation.
MAGIC FILTER
Clean regularly to
stop linting on the
clothes load.
Body
POWDER
DETERGENT BOX
NOTE
Parts can be different according to the model.
CASTORS
Use for easy
translocation
(at rear bottom edge)
Accessories
NOTE
Water supply hoses
Drain hose
Anti-rat cover
Snap Ring
SOFTENER
INLET
Do not open
1 Each for COLD and
HOT water
NOZZLE
