LG WFS1638EKD Service Manual

10
3. OPERATING INSTRUCTION
3-1. IDENTIFICATION OF PARTS
POWDER AND LIQUID
DETERGENT BOX
WAT ER
SUPPLY HOSE
Make sure the
water does not
leak.
POWER PLUG
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its
service agents or
similarly qualified
person in order to
avoid a hazard.
Multi Clean Filter
DRAIN HOSE
for pump model
Check if the drain
hose is hung up
before operating the
washing machine.
BASE
FUNCTION
SELECTOR
TUB
START/PAUSE
BUTTON
Use to start or
stop the washing
machine
temporarily.
ADJUSTABLE LEGS
Use to level the washing
machine for correct
balance & spin
operation.
DRAIN HOSE
for non pump
model
BODY
