LG WFS1638EKD Service Manual

43
ERROR
OVER
FLOODING
ERROR
PRESSURE
SENSOR
MOTOR
ERROR
Water Pressure
Switch is off.
Check water leakage or
whether the drain hose is
hung on to drainage which is
0.9 m obove from floor.
Check blockage of air hole
or air tube.
Check &repair air leakage at
the air hole of outer tub the
air tube or connection parts.
Connector the PRESSURE
S/W ASM or BLUE 4 pin
connector to P.W.B ASM has
bad connection.
PRESSURE S/W is bad. (In
the initial state of QC TEST
MODE, the number on the
DISPLAY is less than 60 or
more than 104)
Connector the HALL Sensor
or Natural 6 Pin connector
to P.W.B ASM had bad
connection .
Connector the stator ASM,
and YELLOW 3 Pin or
Natural 6 Pin connector to
P.W.B ASM had bad
connection
Hall sensor is bad.
Locked by Bearing Housing
Hang drain hose which is
minimum 0.9m above from
floor.
Replace pressure sensor
switch
Remove the foreign objects
in pressure sensor switch
Correct the connector
contact.
Replace PRESSURE S/W
ASM.
Correct the connect contact.
Change Stator ASM.
Change Bearing Housing
ASM.
Change P.W.B ASM.
Change Stator ASM.
ERROR DECISION
BASIS
CAUSE FOR ERROR
OCCURRENCE
REMEDY
