LG WFS1759EKD Service Manual

10
3-1. IDENTIFICATION OF PARTS
3. OPERATING INSTRUCTION
* WATER SUPPLY
HOSE
Make sure the water
does not leak.
SOFT SAFETY DOOR
TEMPERED GLASS
POWDER AND LIQUID
DETERGENT BOX
BLEACH
DISPENSER
FUNCTION
SELECTOR
TUB
BASE
DOOR SWITCH
JET SPRAY CAP
* DRAIN HOSE
for non pump
model
START/PAUSE
BUTTON
Use to start or stop
the washing
machine
temporarily.
* POWER PLUG
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its
service agents or
similarly qualified
person in order to
avoid a hazard.
* DRAIN HOSE
for pump model
Check if the drain
hose is placed into
the laundry tub and
secured before
operating the
washing machine.
