Open the door.
Unscrew the 4 screws from the hinge.
(Use the 8mm tool.)
Open the door and remove the gasket using
the special gasket pliers.
Unscrew the 2 screws.
Disassemble the door upward.
NOTE
• Reconnect the connector after replacing
the door switch assembly.
1
3
1
2
2
DOOR
DOOR LOCK SWITCH ASSEMBLY
79
