Liberty 514 - Pre-Assembly Guide; Tools Required for Assembly; Parts Identification List

PRE-ASSEMBLY
Estimated Assembly Time : 10 minutes (not including mounting the hose reel)
PARTS LIST
A. Cross Brace (2) B. Reel Side (2) C. Crank Handle (1) D. Exit Tube (1) E. Left Side Frame (1)
F. Right Side Frame (1) G. Lower Frame Bar, Front (1) H. Upper Frame Bar (1) I. Axle (2)
J. Supply Tube (1) K. C-Shaped Lock (3) L. Lubricant Tube (1) M. Lower Frame Bar, Rear (1)
N. Leader Hose (1) O. Cross Brace Screw (4) P. Left Swing Arm (2) Q. Right Swing Arm (1)
R. Wheel (2)
2
IMPORTANT: LAY OUT ALL PARTS AND FASTENERS. MAKE SURE ALL PARTS ARE ACCOUNTED FOR.
IF ANY PART IS MISSING PLEASE CONTACT LIBERTY GARDEN PRODUCTS AT 1-866-820-5805.
DO NOT CONTACT THE RETAILER. VISIT OUR WEBSITE, WWW.LIBERTYGARDENPRODUCTS.COM
OR E-MAIL CUSTOMERSERVICE@LIBERTYGARDEN PRODUCTS.COM FOR MORE INSTRUCTIONS.
