CL-2 Service Manual
6. Error Code
Error Code Explanation
ERR_CODE_JAM When the notes Jammed
ERR_CODE_UVSEN Problem with UV Sensor
ERR_CODE_USSEN Problem with US Sensor
ERR_CODE_MGSEN Problem with MG Sensor
ERR_CODE_CISSEN Problem with CIS Sensor
ERR_CODE_MAINMOTOR Problem or False working of Main motor.
ERR_CODE_FEEDMOTOR Problem or False working of Feed motor.
ERR_CODE_CNTSEN_L Count Sensor Error
ERR_CODE_CNTSEN_R Count Sensor Error
ERR_CODE_LAN LAN connection Error
ERR_CODE_FEEDING Feed motor is rotating without feeding notes.
ERR_CODE_OVERCOUNT When the counted notes are more than real notes amount.
ERR_CODE_DOUBLE Double notes feeding detected
ERR_CODE_CHAIN Short size is bigger than standard
ERR_CODE_SHORT Width size is bigger than standard
ERR_CODE_HF Folded or Cut by half size note detected
ERR_CODE_TIMEOUT Failed to get recognition result from Image
ERR_CODE_ANGLE Tilted notes detected
67
