Lidix CL-2 - Page 99

CL-2 Service Manual
9
. Accessories & Specification
99
NO NAME Quantity
1 Power code 1 set
2 User’s Manual 1 set
NO NAME
1 External Display (2-Line FND or LCD)
2 Thermal Printer (2 or 3 inch)
1) Accessories
2) Options
CONTENTS DESCRIPTION
Speed
Piece Counting 1000 / 1200 / 1500 notes/min
Value Counting 800 / 1000 / 1200 notes/min
Serial No. Printing 800 notes/min
Operating Mode
Mix, Single, SP, DIR (Face & Orientation), Serial No.
(Depending on the currency, Serial Mode is not available)
Software Upgrade Off-line : SD Card
Interface LAN, SD CARD, RS232C
Multi Currency
Processing
Up to 20 Currencies (Auto Currency Function is available)
Electrical Spec AC 100-240V, 50~60Hz
Dimension 270(W) x 232(D) x 226(H) mm
Features 1) Counterfeit Detection: UV, MG, MT, IR, FL 2) 4.3” Full Color LCD Touch Screen
Specification
