Fig. 1 (Left-view) Fig. 2 (Right-view)
GENERAL INFORMATION
Fr. fender Headlight Headlight cowl Fr. winker
Rearview mirror Fuel tank Fuel cock Carburetor Seat
Taillight Rr. rail Rr. fender Rr. winker Chain Chaincase
Side stand Engine code Gearshif pedal Horn Nameplate
Rr. reflector Kick-starter Fuel filler cap Fr. shock absorber
Fr. wheel VIN Exhaust muffler Rr. brake pedal
Main step Pillion step Rr. brake Rr. wheel
PARTS LOCATION (Fig. 1-2)
