4. Installation and parts list
Carefully take out the treadmill from the
shipping carton. Ensure that none of the parts
is not missing (picture no. 1).
Take 4 pcs of screw M8*28 and 4 pcs of screw
M8*42 and washers and attach the
left and right vertical beams to the
part of treadmill. Do not tight the
screws fully before complete
the installation.
Take 2 pcs of screw M8*25 and attach
them to vertical beams. When
mounting, make sure that the cables are
located in the frame to prevent them
from pinching.
Remove screw M5*20 on the
console, keep them aside to use in
later steps, as shown bellow:
