Remove the console and connect the
signal line. Adjust the bracket position
and secure it with M5 * 20 screw.
Use the combination wrench to
remove the four M5*14 screws on both sides of the base, then put the left and right
covers on the base respectively.
Place the red security key with the magnetic side at the marked position on the
control panel.
Note: The machine can only be started with the safety key located in the correct
position. Keep the safety key away from children.
Note: Ensure that all screws are firmly tightened and that you have no leftover parts.
