LifeSafety Power FlexPower Vantage FPV6-R8E1

FlexPower Vantage R8 Access Power System - Installation Manual 12
R8 Power Control Accessory Board Specifications
Power Input
Voltage 12 or 24VDC nominal ±15%
Current 12A maximum
Standby Current 700mA (R8)
All lock control relays active
Zone Input
Zone Count 8
Max Current 10mA
Zone Output
Zone Count 8
Voltage Same as input
R8 Current 3.0A resistive
R8P Current 2.5A resistive (Class 2 Power Ltd) (R8P)
Fuse
3A ATM automotive style (R8)
FPV102-R8E1 / FPV104-R8E1 Electrical / Mechanical Specifications
FPV102-R8E1 FPV104-R8E1
AC Input Voltage 120VAC or 230VAC at 50-60Hz 120VAC or 230VAC at 50-60Hz
Current 3A 5.7A
Standby Current 110mA 160mA
DC Output
(Auxiliary power-limited
output rated at 1.5A.
Total current must not
exceed max current)
Voltage 11.3 - 12.0V 23.4 - 25.0V
Max Current 10A 10A
Ripple & Noise 120mV 240mV
Regulation ±2% ±2%
Efficiency 89% (120VAC
60Hz In, Full Load, No Batt)
91% (120VAC
60Hz In, Full Load, No Batt)
Auxiliary Output Current 1.5 A max 1.5 A max
Battery Size & Type 4-80AH Lead Acid
or Gel Cell
4-80AH Lead Acid
or Gel Cell
Charge Current 1.6A (±10%) maximum.
Charger current is 1.6A max for high
setting, 0.8A max for low setting.
1.6A (±10%) maximum.
Charger current is 1.6A max for high
setting, 0.8A max for low setting.
Low battery disconnect to
prevent deep discharge
70% of nominal
battery voltage
70% of nominal
battery voltage
Fuse Rating Battery ATM 15A ATM 15A
BTU Output BTU/Hr 55 92
Fault Setpoints Low AC 95V (±6%) 95V (±6%)
Output Voltage ±10% of Nominal ±10% of Nominal
Fault Relay Contacts AC FLT 1A at 24VDC 1A at 24VDC
SYS FLT 1A at 24VDC 1A at 24VDC
Operating Temperature 0 – 49C° 0 – 49C°
Enclosure Size / Weight 14H x 12W x 4.5"D | 14 lbs 14H x 12W x 4.5"D | 14 lbs
