LifeSpan Unity User Manual

16
Assembly Instructions
Step 5: Attach Desk Base
Frame to Drive System
A. Remove the two pre-
installed M8 Nuts,
Washers and Lock
Washers (16) on the Low
Connection Point(A) of
the Drive System (3) as
shown in the image to
the right.
B. Remove the two pre-
installed M8x40L Bolts,
Washers and Lock
Washers(17) on the Top
Connection Point(B) of
the Drive System (3).
C. Slide together the Desk
Base Frame (8) to the
Drive System(3). They will
connect at the bottom
and top.
D. Slide the M8x40L Bolts,
(17) into place for the
top connection.
E. Using Washers, Lock
Washers, and Nuts (16)
attach Desk Base Frame
(8) to Drive System (3) on
the bottom. Fully tighten
all hardware.
F. Finish the top
connection using
M8x40L Washers, Lock
Washers, and Nuts(17)
to attach Desk Base
Frame(8) to the Drive
System(3). Fully tighten
all hardware.
PRE-INSTALLED
M8 Lock Washer,
Washer,
Nut
8
8
17
17
A
B
3
16
Use Socket
with
Allen Wrench
Use Socket
with
Allen Wrench
PRE-INSTALLED
M8 x 40L Bolt
(x2)
