Lifetime 1529 - SEC 1.1 Pole Assembly: Connecting Top and Middle Poles

15
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
ALH
ALF
ADS
"MJHOUIFIPMFJOUIFTop Pole (ALH)XJUIUIFTMPUJOUIFMiddle Pole (ALF)BOE
TMJEFUIF5PQ1PMFPWFSUIF.JEEMF1PMF*OTFSUB1/4” x 3/4” Screw (ADS)
UISPVHIBDomed Countersink Washer (CIH)BOEJOUPUIFTNBMMIPMFJOUIF5PQ
1PMFBOEJOUPUIFTMPUJOUIF.JEEMF1PMFBTTIPXO
SEC
1.1
ADSY
ALH
ALF
Warning
Sticker
CIHY
CIH
Note: The 1/4” x 3/4” Screw and Domed Countersink Washer
should be fl ush with the Pole, but will spin freely once installed.
Do not jam the Poles together until instructed.
!
