64
TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS / INSTRUMENTAL Y HERRAJE REQUERIDOS
X SECTION 5 (CONTINUED) / SECTION 5 (SUITE) / SECCIÓN 5 (CONTINUACIÓN)
6
ENG
DSA
DSA
BTS
BTS (x5)
ENG (x5)
DSA (x5)
Interior View / Vue intérieure / Vista interior
Exterior View / Vue extérieure / Vista exterior
5.3
5.7
1/2 in/po (≈13 mm)
(1)
(1)
3/16 in/po (≈5 mm)
