9
TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS / INSTRUMENTAL Y HERRAJE REQUERIDOS
X SECTION 1 (CONTINUED) / SECTION 1 (SUITE) / SECCIÓN 1 (CONTINUACIÓN)
1.3
• Insert the tabs at the bottom of the Front Panel (AMZ) into the slots in the Floor Panel.
• Insérez les languettes au bord inférieur du panneau avant (AMZ) dans les fentes dans le panneau de plancher.
• Inserte las lengüetas al borde inferior del panel delantero (AMZ) dentro de las ranuras en el panel de piso.
1.4
• Slide the Front Panel to the left until it stops.
• Faites glisser le panneau avant à gauche jusqu’à ce qu’il s’arrête.
• Deslice el panel delantero a la izquierda hasta que se pare.
AMZ
