Lifetime 65009 - Attaching Lock Bracket

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
14
SEC
AWA
1/2”
AVVX
AVWX
AVXX
AVUX
AVX
AVX
AVW
AVW
AVU
AVU
AVV
AVV
SEC
2.2
2OTATETHE!XLE7ELDMENTAWAYFROMTHE4UB0LACETHELock Bracket (AWA) over the two holes towards the front
OFTHEBOTTOMOFTHE4UBASSHOWN,IGHTLYSECUREWITHTWO5/16” x 1” Round Slotted Bolts (AVV)TWO5/16”Flat
Washers (AVU)TWO5/16” Lock Washers (AVW)ANDTWO5/16” Threaded Hex Nuts (AVX).
Note: Do not tighten Nuts yet.
!
2
2.
