Lifetime 65009 - Page 19

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
19
SEC
AWD
AWE
AVX
AVW
BJW
AVV
SEC
2.7
4URN9ARD#ARTUPRIGHT/NTHEINSIDEOFTHE4UBPLACETHEBacking Plate (AWF) over the two holes towards the
FRONTOFTHE4UBANDINSERTTWO5/16” x 1” Round Slotted Bolts (AVV) through the holes. Place the Tongue Mounting
Bracket (BJW)OVERTHE"OLTSANDSECUREWITHTWO5/16” Lock Washers (AVW)ANDTWO5/16” Threaded Hex Nuts
(AVX).
SEC
2.8
2OTATETHE4ONGUEUPWARDSANDINSERTONE3/8” x 5” Carriage Bolt (AWE)THROUGHTHE4ONGUE-OUNTING"RACKET
AND4ONGUEANDSECUREWITHONEThreaded Knob (AWD).
Note: Note the angle of the ends of the Tongue Mounting Bracket.
!
