Lifetime 80193 - Page 13

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
13
SEC
Front Rear
SEC
1.7
Slide the second Center Table Support (DAI) up into place as shown. Secure the Center Table Support to the Frame
using the required hardware. Do not completely tighten Nuts until instructed.
1
DAI
DAAY
DAA
DAA
DAGY
DAG
3/16”
Note: For 6’ round tables, attach the Center
Table Supports using these holes.
!
Note: For 5’ round tables, attach the Center
Table Supports using these holes.
!
