Lifetime 90160 - Page 22

22
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
ADSX
Align the hole in the Top Pole (ALH) with the slot in the -IDDLE0OLE!,& and
slide the Top Pole over the Middle Pole. Insert a vXv3CREW!$3
through a Domed Countersink Washer (CIH), into the small hole in the
Top Pole, and into the slot in the Middle Pole as shown. The Screw head
SHOULDlTINTOTHE#OUNTERSINK7ASHER
SEC
2.3
ALH
!,&
Note: The 1/4” x 3/4” Screw should be fl ush with the Pole, but
will spin freely once installed. Do not jam the Poles together
until instructed.
!
ALH
!,&
ADS
CIH
CIHX
