22
TOOLS AND HARDWARE REQUIRED
X SECTION 2 (CONTINUED)
2.7
• Stand the assembly on its feet. Using a ladder, attach the the Trapeze Swing Bar (CRR) to the Monkey Bars
Assembly with the hardware indicated. Install the hardware nearest to the Pendulums fi rst.
3/16 in/po (≈5 mm)
(2)
DSA (x4)
BTS (x4)
(1)
CRR
DSA
BTS
BTS
BTS
BTS
Pendulum
!
• Do not completely tighten the hardware until instructed later in the assembly.
