TOOLS AND HARDWARE REQUIRED
X SECTION 5 (CONTINUED)
5.8
• Slide the Angled Cargo Leg (CAY) into the Ladder Cap (CAC) and Left Vertical Pole (CBK). Rest the Angled Cargo Leg against the
Cargo Side Deck Support in the location shown. Do not secure it at this point in the assembly.
CAC (x1)
3/16 in/po (≈5 mm)
(2)
CAY
!
• DO NOT secure the Angled Cargo Leg with any harware until instructed later in the assembly.
CAC
6.3
CBK
