51
TOOLS AND HARDWARE REQUIRED
X SECTION 7 (CONTINUED)
• Place a Climbing Wall Panel (CBX) on the ground, or in a safe drilling position. The indentations in the Climbing Wall
indicate the locations needed to be drilled. Using a 1/4 in Drill Bit (not included), drill completely through the
plastic.
7.1
!
• Repeat this step to drill through the indentations in the other Climbing Wall Panel.
1/4 in/po (≈7 mm)
(1)
Drill holes at the angle shown
!
• The panels have fi ve indentations on each side for a total of 10 indentations per panel. Make sure to drill through all 20
indentations.
(1)
To Next Page
