5
PART 2: INSTALLATION
• Orient the seat as shown. Press the front end of the frame into the clips
indicated, then snap the top of the clip into place. The rear of the seat
frame rests in the slots shown.
• Seat frame shown without covering
for illustrative purposes only. Kayak
appearance may vary from the
model shown.
• Secure the long center strap on the underside of the seat cover to the
tie-off bracket on the hull. This will prevent the seat from sinking in the
event that the seat becomes seperated from the hull in the water.
Strap
View from
Underside of Seat
Tie-off Bracket
Strap
• Kayak appearance may vary
from the model shown.
!
!
