Lifter HX10M - Page 4

3
“C”
“E”
“D”
l1
l2
l
s
(y)
h3 h13
h14
1461
c
m2
Q
b11
b5
e
b10
b1
l6
Wa
x
a/2=100 a/2=100
Ast=Wa+l6-x+a
102,5°
102,5°
1.2 1150x540 1150x680
1.5 Q kg 1000 1000
1.6 c mm 600 600
1.8 x mm 993 993
1.9 y mm 1236 1236
2.1 kg 104 111
2.2 kg 339/765 344/767
2.3 kg 79/25 84/27
3.1 P/P P/P
3.2 200x45 200x45
3.3 80x50 80x50
3.4 --
3.5 2/2 2/2
3.6 b
10
mm 150 150
3.7 b
11
mm 447 587
4.4 h
3
mm 715 715
4.9 h
14
mm 415/1250 415/1250
4.15 h
13
mm 85 85
4.19 l
1
mm 1526 1526
4.20 l
2
mm 376 376
4.21 b
1
mm 540 680
4.22 s/e/l mm 48/160/1150 48/160/1150
4.25 b
5
mm 540 680
4.32 m
2
mm 21 21
4.34 A
st
mm 1779 1779
4.35 W
a
mm 1372 1372
5.2 pompate/strokes 62/30 62/30
5.3 m/s 0.06/0.04 0.06/0.04
