Lifter HX10M - Page 52

Functional Group Functional Group Number Table Number Revision
Bertriebsgruppe 1 - 0
(02-2009)
HX10M-2008-L.540 - Machine code: GT0420VBC00 Spare Parts Catalogue HX10M-2008-L.540 - Revision: 0 (2/2009)
Position Part Number Description Notes
300 G044420 Federbüchse -
301 S000017301 Platte -
302 G001143 Feder (pumpkolben Hx) -
303 P0C700001 Zylinder Ab Serie 725245 -
304 P0P600001 Kolben D15mm (ab 725425) -
305 G096004 Cu-dichtung 25.5x31x1 -
306 S0042015006 Hülse -
307 S000017603 Kolben Hx10m -
308 G016393 Bronzelager -
309 S0004013002 Bolzen -
310 G044344 Spannstift 8748 D4x24 -
311 G044318 Federbüchse -
312 S000017065 Bolzen -
313 S0042013004 Rolle -
314 S0004010036
Ventil ( Hebe )
-
315 S0004018002 Bronzelager 20x22x10 -
316 P0PP00005 Pumpengehäuse Hx10m -
317 G010220 Lager 6012 Rs 60x95x18 -
318 G042120 Seeger-ring 22x18,5x1mm -
319 G091101 Dichtung F.scheibe -
320 S0041015002 Bolzen 55mm -
321 G042160 Seeger-ring 7435 E 60 -
322 S0042010013 Gelenkkranz L540 -
323 S0042015012
Achse
-
324 S0012010216 Pendelachsel (ab Serie 711103) -
325 S000007036 Lenk-rad Nylon Schw./poly 200x45 (basic) -
S0004010186 Lenk-rad-nylon -
326 S000003901 Pedal -
327 G016104 Kugel (d 7,938 Mm) -
328 S0042018011 Tank Hl/hx (235mm Hoch, 65 Mm D) -
329 S0042018010 Schutz -
330 S0042018013
Verschlußstopfen
-
331 S0042011003 Paar Halbringe -
332 G041904 Beilagscheibe -
333 S000017508 Hülse -
334 S000017507 Kolben -
335 S0042018003 Ring -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - http://www.pramacparts.com This document was printed on 3 November 2014
