Functional Group Functional Group Number Table Number Revision
Rahmen 2 - 0
(02-2009)
HX10M-2008-L.540 - Machine code: GT0420VBC00 Spare Parts Catalogue HX10M-2008-L.540 - Revision: 0 (2/2009)
Position Part Number Description Notes
100 V000017004-PRAMAC Rahmen Hl/hx10e/m Grün Alt V0041210032 -
101 S0041215026 Exzenter -
102 G016395 Bronzelager -
103 S0041218009 Distanzscheibe Weiss (kunststoff)hl+hx -
104 G042122 Seeger-ring -
105 G016304 Büchse 22x26x50 -
106 S0041218010 Distanzstück -
107 G042120 Seeger-ring 22x18,5x1mm -
108 S0041210042 Last-rolle Hl Nylon 80x50 -
109 S0041215025 Bolzen 70mm -
110 S0041210036
-
111 S0041210034
-
112 S000017045 Stabilisator Hx10m/e -
113 S0041016003 Distanzstück -
114 S0041218008 Rolle -
115 S0041210038 Pfosten -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - http://www.pramacparts.com This document was printed on 3 November 2014
