Functional Group Functional Group Number Table Number Revision
Operational group 1 - 0
(02-2009)
HX10M-2008-L.540 - Machine code: GT0420VBC00 Spare Parts Catalogue HX10M-2008-L.540 - Revision: 0 (2/2009)
Position Part Number Description Notes
300 G044420 Cylindrical Plug D4x28 H8 -
301 S000017301 Spring Guide Plate Hx10m Burnished -
302 G001143 Plunger Recovery Spring Hx10m -
303 P0C700001 Cylinder + Gaskets Hx10m -
304 P0P600001 Plunger Complete Hx10m -
305 G096004 Copper Washer 25.5x31x1. Inner Diam. Tol. 0/+0.5 - Outer Diam. Tol. -0.5/0 -
306 S0042015006 First Stage Slide Guide Bushing Hl10m -
307 S000017603 First Stage Guide Hx10m (machined) -
308 G016393 Self-lubricating Bushing Fe 12x16x20 -
309 S0004013002 Pump-up Roller Pin Gs -
310 G044344 Elastic Peg Spirol 8748 D 4x24 -
311 G044318 Elastic Peg Spirol 8748 D 4x40 -
312 S000017065 Chain Guide Pin -
313 S0042013004 Complete Pump-up Roller Hl10m -
314 S0004010036 Complete No Return Valve Gs (spare Part) -
315 S0004018002 Body Pump Bushing Gs (20x22x10) -
316 P0PP00005 Body Pump Hx10m -
317 G010220 Bearing 6012 Rs(60-95-18) -
318 G042120 Outer Seeger 7435 E 20 -
319 G091101 Wheel Dustguard Tp 47x20 Sp3.9 Tellure -
320 S0041015002 Pin Cross Hl10m/ped.l-k20 Burnished -
321 G042160 Outer Seeger 7435 E 60 -
322 S0042010013 Cross Hl10m (l.540) Machined -
323 S0042015012 Balancing Axle Hl10m "burnished" -
324 S0012010216 Balancing Painted Gs/cat -
325 S000007036 Wheel Injected Polyurethane/nylon Black Color D200x45+bearings '07 Gs -
S0004010186 Nylon Wheel D200 With Bearings -
326 S000003901 Opening Spill Pedal '07 Gs -
327 G016104 Ball 5/16" (mm7,938) -
328 S0042018011 Tank Hl10m (rubber) -
329 S0042018010 Oil Tank Protection Hl10m -
330 S0042018013 Oil Tank Cap Hl10m (nylon) -
331 S0042011003 Semi-rings Couple Hl10m -
332 G041904 Plain Washer 6592 10.5x21 Zn -
333 S000017508 Guida Secondo Stelo Hx10m '05 -
334 S000017507 Secondo Stelo Hx10m '05 -
335 S0042018003 First Stage Sliding Ring Hl10m -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - http://www.pramacparts.com This document was printed on 3 November 2014
