Functional Group Functional Group Number Table Number Revision
Chasis 2 - 0
(02-2009)
HX10M-2008-L.540 - Machine code: GT0420VBC00 Spare Parts Catalogue HX10M-2008-L.540 - Revision: 0 (2/2009)
Position Part Number Description Notes
100 V000017004-PRAMAC Bancada Hx10m/e L.540 Pint.verde Pramac -
101 S0041215026 Excentrica Registro Hl10e Bruñido -
102 G016395 Boccola Autolubricante -
103 S0041218009 Espaciador Brazos Hl10m/e -
104 G042122 Seeger Externo 7435 E 22 -
105 G016304 Buje Autolub. Fe 22x26x50 -
106 S0041218010 Espaciador Montante Nylon Hl10m/e -
107 G042120
Anillo Seeger Externo 7435 E 20 Clip Fijacion Rueda Din 471-e D.20
-
108 S0041210042 Rodillo Nylon D80x50 + Cojinetes -
109 S0041215025 Pasador Rodillo Hl10e Bruñido -
110 S0041210036 Brazo Izq Painted Hl10e -
111 S0041210034 Brazo Dcho Painted Hl10e -
112 S000017045 Stabilizing Eccentric Hx10m/e '10 -
113 S0041016003 Espaciador Excentrica Hl10m/e -
114 S0041218008 Rodillo Guia Hl10e -
115 S0041210038 Montante Hl10m/hl10e 540 Painted -
IMPORTANT NOTICE: Before using this information please check if updated releases have been published on Pramac Service & Parts Online Center - http://www.pramacparts.com This document was printed on 3 November 2014
