LEGO PICKUP TRUCK 10290 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 22
Legend
DISCONNECT
CONNECT /
RECONNECT
TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.
Dark Grey Plate 1x4
Connect the USB
Power Cable into it’s
final position
To Next Page
