power in
out
power end
out
in in
10
● After doing the above operation and making sure all the devices had been installed with
natural operate, press the power switch to check whether everything is working normally.
● Connection to the eiectricty mains must be carried out by a qualified electrical installer.
● The fixture power supply can not be more than 2pcs pre line.
The N terminal is connected
with the blue line.
Ground
The L terminal is connected
with the brown line.
Watertight seal ring
Watertight seal ring
●The fixture delivers a three-core waterproof plug.
