Lightmaxx Tour Spot ARC MKII User Manual

ENGLISH
8-Channel mode (A001):
Static, Auto or Sound mode:
The device contains automatic programs that run according to fixed schemes (Auto) or are
recalled via the built-in microphone to match the music (Sound). The selection of the respective
mode takes place via the menu directly on the device.
If you connect several devices of the same type via DMX, they can be controlled simultaneously
via the master device. To do this, set the desired function "Master" on the first device of the line,
the other devices of the series must now be set as "Slave". Now the first device of the line gives
the function to all other devices and all devices run simultaneously.
Operation:
Start:
Connect the device to the mains and wait a few seconds until it is ready for operation.
Channel
Value
Function
1
000-255
RGBW Dimmer (dark to light)
2
000-255
Red Dimmer (dark to light)
3
000-255
Green Dimmer (dark to light)
4
000-255
Blue Dimmer (dark to light)
5
000-255
White Dimmer (dark to light)
6
000-255
RGBW Strobe (slow to fast)
7
000-050
DMX 8 Channel control
051-100
Color macros
101-150
Fixed colour change
151-200
Color change fade
201-250
Pulsating colour change
251-255
Music control
8
000-255
Speed (slow to fast)
