Connections and controls:
No.
Designation
No.
Designation
1
9 x RGB Inner LEDs
7
Carrying handles
2
33 x RGB Outer LEDs
8
Power connection (PowerCon)
3
Fog nozzle
9
DMX-Input (3-pole)
4
Fluid container with closure
10
DMX-Output (3-pole)
5
ON/OFF switch
11
Fan
6
Operating elements (display/keys)
12
Ring eye for e.g. Safety
