Lightobject Z-table/Bed - Introduction to Motorized Z Table;Bed; Included Components for Z Table;Bed Kit

V2
4/15/2021
3
Introduction
Thank you for purchasing the mini powered Z-table/bed. This mini-powered bed is
designed to perfectly fit the “k40” small desktop CO2 laser machine. The unit comes
as a kit, so it already comes with a lot of parts you need to build it. The purpose of
this power bed is to allow for height adjustment to get better cutting or engraving.
This manual will walk you through successfully assembling of your kit.
What is included
1 Bottom Frame (Blue)
A
4 Threaded-rods with T-screws and nut
G
1 Top Frame (Blue)
B
1 Belt
H
1 Bed
C
1 Stepper Motor
I
1 Belt-tensioner
D
8 Bearings
J
4 poles
E
4 Washers
K
Screws
F
1 Allen key
L
1 motor bracket
M
Spare parts
A
C
B
M
D
F
G
H
I
E
J
K
1
2
3
4
L
