Lightwave link
(runs the show)
Lightwave App
(control any room from anywhere)
Boiler Switch
(turns boiler on/o)
Bedroom 1
Bedroom 2
Lounge
Home Thermostat
(monitors house temp.)
Room Thermostat
(controls several TRVs)
Heating Remote
(sets house temp.)
Window Trigger
(open window turns o TRV)
Electric Switch
(controls radiator)
Example ‘Heating Zones’ (rooms or areas of the house)
Heating System Setup
