2. Use correct screws
Mount the DPG to the tabletop using screws with
the following specifications:
- Ø4.5 mm
- 90° countersink screw
Do not use screws with a milling head as
they will cut into the housing of the DPG.
The screws must be fastened sufficiently without being overtightened. It is not possible to mention a specific
torque as this depends on the type of screw, the material of tabletop and whether there are predrilled holes or
not.
3. Do not overtighten screws.
The screws must be fastened sufficiently, but without damaging the plastic.
4. Mount DPG and make sure that cable is not tightened too much.
When mounting the DPG, it is important to ensure that the cable is not tightened but but has free mobility in the
first centimetres from the housing. We recommend attaching the cable to the tabletop with a clip as shown on the
drawing above.
Find more information about how to use the DPG in this short film: (link)
The above-mentioned link is directly accessible via the label on the cover of the DPG. Use either the QR code or
type in the web address.
