Reminder
The reminder LED is placed in the lower left corner of the DPG1M. The LED is intended to indicate the position of
the desk (sitting or standing height). The indication depends on the reminder interval chosen.
While the user is sitting for an appropriate amount of time according to the set interval, the LED calmly pulsates
green. When the sitting interval runs out, the calm pulsating green turns into fast pulsating orange for one
minute hereafter into static orange to indicate that the user should adjust the desk to standing height. In
standing height, the LED pulsates green until a potential timeout. When the desk is adjusted back to sitting
height, the LED pulsates green until the reminder goes off again.
Reminder restart
The reminder automatically restarts when the desk is lowered to sitting height.
Reminder timeout
After four hours without any action, the LED will time out. When the DPG1M is tilted, the green light turns back
on.
When the LED is enabled for reminders, the DPG1M is no longer in ZERO™ mode as long as the light is
on/active.
Figure 15: Pulsating green LED indicates no need to
drive desk up
Figure 16: Pulsating orange LED indicates that the user needs
to drive his/her desk up
