Melt, Keep warm, and Simmer functions
The first three settings on the control knob are low temperature control functions.
One bar is melt to heat the pot to 45 °C, two bars is 70 °C and three bars is 94 °C.
These temperatures are approximate and depend on the pan quality and volume
of product.
Power level settings
9 power level settings are available. The table gives the percentage of maximum
power for each setting with the time limit for operation at that power.
Power level Low temp
hold
1 2 3 4 5 6 7 8 9
% of power --- 3%
5%
8%
12%
18%
28%
42%
64%
100%
Time limit
(mins)
120 520
402
318
260 212 170 139 113 90
Power boost function
Power boost is activated by turning the control clockwise from level 9. Only one coil
per front to back pair can be boosted at a time.
The power boost will run for a maximum of 10 minutes before reverting to level 9. It
may be boosted again, providing the system internal temperatures are satisfactory.
Automatic heat-up control (AHC)
When activated, the AHC will give maximum power (level 9) to a coil for a pre-set
time before reducing to a lower power level set by the control. To activate, the
control is turned anticlockwise from the ‘Off’ position briefly whilst the ‘A’ symbol
illuminates: the control is then turned clockwise to set the ‘final’ required power (1-
8). The display reverts to the ‘A’ symbol and the hob will run at maximum power for
the time shown in the table, before reducing power to the ‘final’ setting.
Power level setting 1 2 3 4 5 6 7 8
Present time (secs)
40 72 120 176 256 432 120 192
Control lock function
This function prevents unwanted operation of the hob. When the control lock is
active, the ‘L’ symbol is displayed. It operates on pairs of controls (Left, centre and
right).It is activated and de-activated by turning both control knobs anticlockwise to
the control lock position and held for approximately 5 seconds.
