Parking brake ON chime: Sounds when the parking brake is left ON
and the vehicle is driven. If the warning stays on after the park brake is
off, contact your authorized dealer as soon as possible.
Message center activation chime: Sounds when some warning
messages appear in the message center display for the first time.
Overspeed chime (if equipped): Sounds when the vehicle speed
reaches 75 mph (120 km/h) or higher.
GAUGES
Speedometer: Indicates the
current vehicle speed.
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section,
the engine is overheating. Stop
the vehicle as soon as safely
possible, switch off the engine and let the engine cool.
2007 MKX (mkx)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
14
