Protected componentsFuse amp ratingFuse
Restraints control module.
5A
1
35
Auto-dimming rear view mirror.
15A
1
36
Continuous control damping suspension.
Lane keeping system module.
Rear heated seats module.
All-wheel drive relay.
20A
1
37
Heated steering wheel.
Not used (spare).30A38
1
Micro fuse.
2
Dual micro fuse.
Rear Cargo Fuse Box
The fuse panel is located in the cargo area
on the passenger side. Open the fuse panel
cover to gain access to the fuses.
279
MKC (TME) Canada/United States of America, enUSA, Edition date: 01/2016, First Printing
Fuses
