Lincoln LS 2000 - Installation

23. Remove the bolts and the upper intake manifold.
z Inspect the gaskets and discard as necessary.
Installation
1. Position the upper intake manifold and gaskets.
2. Install the fuel pressure sensor shield.
1. Position the shield.
2. Install the nut.
3. Install the upper intake manifold bolts and tighten in the sequence shown.
4. Position the differential pressure feedback EGR and install the nut and stud.
5. Install the upper intake manifold support bolt.
