FLOW TYPE CONTACT COOLER LINDR
5
Beverage connection:
1.
Fill the plastic tank (No.11) with water right up to the overow
(No.11)
CAUTION:
After connecting the cooling coil the water level may drop in
the plastic tank, so check again and add water if necessary.
2.
Connect the cooling machine to the tower (outlet) and the
dispense heads (input), see pages 26 and 27.
CAUTION:
Due to condensation there can be a small amount of water
owing away through the overow.
WE RECOMMEND:
Only use quick couplings to connect beverage hoses. For
the connection of tubes for the beverage use only fittings
and clips specified by the supplier. Use a calibrated tube
6.7 x 9.5 mm.
AFTER THE CONNECTION CHECK IF ALL THE JOINTS ARE PROPERLY SEALED.
Placement of the thermostat:
3.
Model AS has a mechanical thermostat located on the front of
the cooler. See picture
4.
Model CWP
See picture
THERMOSTAT
THERMOSTAT
