1.0 Introduction
Thank you for purchasing the LINDY RS-422/485 Controller. This PCI serial
card enables your computer to support serial RS-422/485 ports with 256Kbyte
FIFO.
2.0 Packing List
Please check if the following items are present and in good condition upon
opening the packaging. Contact your vendor if any items are damaged or
missing.
Hardware:
Serial Communication Board: LINDY PCI Host Controller × 1
Cables:
2 Port, No.51215 : DB25 Male to 2 Port DB9
Driver CD
This User Manual
3.0 Features
Communication speed Maximum 921.6K BPS
BUS interface PCI Local Bus Spec 2.2
Circuit interface RS422/RS485
Communication controller 16C1052
Connector DB9
I/O address Automatic set-up
IRQ number Automatic set-up
Circuit Protection ESD Protector attached
Supporting operating system Windows 98/2000/NT/XP, Linux
